1. Shell processing technology: using laser, bending, cutting, welding, polishing, polishing, and other
processes.
2. Rod length/thickness: 500 (mm) / ¢ 38 stainless steel tube.
3. Adaptation temperature: -40 °C ~ 80 °C. (Need to add temperature control system).
4. Working environment: indoors and outdoors.
5. The Rod unlocks quickly and reliably.
6. When power is off, the rod automatically drops.
7. Entrance and exit setting: Allowed or Forbidden.
8. Customized function: Counting function, Memory Function, LED indicator, Voice broadcast.
9. Can be connected to standard input and output interface.
10. High-level semi-automatic intelligent mechanism.
11. Easy to work with the Access control system
12. Passage LED indicator, Passage Mode setting.
13. Using a standard electrical interface, it can easily integrate magnetic stripe cards, barcode cards, ID cards, IC cards, ID cards, and other card readers on the device.
2) It has the function of power off and drop bar, and remote control can also be added for drop bar control;
3) LED indicator light, the valid card is green, and the standby is red;
]]>
]]>- Problem-self-checking function
- Arm Turning: Bi-direction
- When power off, arm open automatically and power on again, arm will be held automatically
- When valid card read and passenger passed, arm can be delayed to close from 1-60s which can be set in the control panel
- Auto-reposition function: After card read, passenger doesn’t pass within regulated time, turnstile will cancel order automatically. And the regulated time can be set by managers
- Anti-rush function: if there is no open single, arm will be holding tightly
- Stable running with little noise
2. Power Consumption: 100W/24V
3. Temperature: -15 to 60 degrees
4. Humidity: <95%, without concretion
5. Passage Width: 600mm
6. Passing Speed: 30 persons/min (normal open), 20 persons/min (normal close)
7. Arm Open/Close Time: 1s
8. Input Interface: +12V electrical signal or impulse signal with width more than 100ms, drive current >10mA
9. Communication Interface: RS485 (Distance: <=1200m)
10. Material: Housing – mild steel Arm – Plexiglass
11. Housing Dimension: 1200*280*1000mm
12. Arm Length: 260mm
13. Working Environment: Indoors or outdoors with shed
Structure:
1. Dimension
1200*280*1000mm
2. Arm color
● transparent
○ Blue
○ Red
○ Customer drawings
3. Drawings
Finishing:
● Brushed
○ Grit satin
○ Hot-galvanized
○ Powder coated in colors
Constructions:
Turnstile arm
Plexiglass
Guiding elements inside and outside Light metal casting, natural anodized
Portal frame Made of steel with space reserved for installations
Working principles:
● The arm will open automatically when we send relay signal to turnstile
Power supply:
● 220V AC @ 60HZ
○ 230V AC @ 50HZ
○ 110V AC @ 60HZ
○ 220V AC @ 50HZ
Working power: 24V DC
Controlling way:
● Relay signal
● RS485
