- Video Quality: FHD (Full High Definition) lens
- Chipset: Ambarella chipset, known for low power consumption and high-quality video
- Lens: 140° wide-angle lens to enlarge the field of view
- Operation: Simple one-button control on the front to start and stop recording
- Model Name: DSJ-K80 (though the document provided shows DSJ-BO3 as a “common recorder” for police, suggesting K80 is a similar model in the DSJ line)
Full Gigabit Switch. This is a high-performance, low-power all-gigabit Ethernet switch, which is the first choice for small and medium-sized local area networks. FEATURES: Support IEEE 802.1Q VLAN * Full and half duplex operation with IEEE 802.3X flow control and back pressure * Support link aggregation (IEEE802.3ad standard) for 8 groups of link aggregators up to 8 ports per group * Support 4K MAC address * Support EEPROM configuration * Support IVL, SVL, and IVL/SVL * Support IEEE 802.1x access control protocol * Support IEEE 802.3az EEE (Energy-Efficient Ethernet) * Support 25M clock, RFC MIB counter
]]>
Warranty：1 year
This converter will give your Copper Gigabit connection the ability of interface with fiber connection over a distance up to 80 km! 10/100/1000 means that the media converters can convert the electrical signal of a10/100/1000 Ethernet signal from copper to fiber. This solution will offer a low-cost integration option for network managers who want to migrate from 10/100 networks to Gigabit Ethernet. Gigabit only switches can now be connected to 10/100 networks without the need to upgrade the 10/100 side.
Features
- Complies with IEEE 802.3, IEEE 802.3u, IEEE802.3z, IEEE802.3ab, IEEE 802.3x auto-negotiation
- Works at 10Mbps or 100Mbps, full or half-duplex mode, or 1000Mbps full-duplex mode
- Extends distances ranging from 550m(multi-mode fiber) to 120km(single-mode fiber)
- Supports auto MDI/MDIX function
- Status LED for easy monitoring of device status
- Supports jumbo frame size 9K bytes
- External power supply
- Supports independent LFP function
- FCC Class A & CE approved
Specifications
| Parameter | Specifications |
| Access mode | 10/100/1000Mbps |
| Standards | IEEE802.3, IEEE802.3u, IEEE802.3z/ab, 10/100/1000Base-T/SX/LX/BX/EX/ZX |
| Interface | 2 x Ethernet port (RJ45) 10/100/1000Base-Tx 1 x Fiber port (1×9) 1000Base-Fx |
| Wavelength | 1310nm Singlemode |
| Transmission distance | Fiber Port: 40km RJ45 Port: 100m |
| Fiber port connector | SC/PC, ST/PC, FC/PC optional |
| Conversion means | Store and Forward mode |
| Flow control | Full duplex: flow control, Half duplex: back pressure |
| Input voltage | AC 110V~240V, DC 5V+2A, DC-48, DC24V, DC12V |
| Power consume | <3W |
| Operating temperature | 0~50ºC |
| Operating humidity | 5%~90% |
| Maintaining temperature | -40~70ºC |
| Maintaining humidity | 5% ~ 90% non-condensing |
Sensitivity level: 100~200(optional)
Each zone sensitivity level: 200 (Adjustable)
Power consumption: 12 W
Working frequency :1~50 bands
Highest standard: Metal size ≥ 6 g
Vertical dimension: 2200x860x440mm
Vertical channel size: 2000x700mm
Customizable width : 700~1500mm
Working voltage: AC110V~240V 50/60Hz
Working environment temperature: -40℃~+85℃ ]]>
| Specification | ||
| Frequency | 13.5Mhz |  |
| Support Read chip | TK4100/ TK4200/EM4100/EM4200 | |
| Speed | 106Kbit/s | |
| Reading distance | 1-10cm | |
| Power supply | DC 5V(±5%) | |
| Current | <100Ma | |
| Interface | USB | |
| Indication light | 1 DUAL LED,1 BUZ | |
| Working temperature | -10 ~ +70 degree | |
| Storage temperature | -20 ~ +80 degree | |
| Max. humidity | Relative humidity 0 ~ 95% | |
| Size | 75 x 21 x 7mm | |
| Operation system | WindowsMacintoshLinuxAndroid | |
How to USE ?
1. Connect the RFID USB Pen Reader to the computer USB port.
2. The reader will ‘drip’ sound and flash about that power successfully, and then half a second after the ‘drip’ sound and flash about that device selftest successfully, without Install any drivers, windows will automatically recognize it.
3. Open one EXCEL or WORD ,the card number would be input by itself .Connect USB pen reader to OTG cable , OTG cable to smartphone , open any file can type letters, the card number would be input by itself.
| Specification | ||
| Frequency | 125KHZ | |
| Support Read chip | TK4100/ TK4200/EM4100/EM4200 | |
| Speed | 106Kbit/s | |
| Reading distance | 1-10cm | |
| Power supply | DC 5V(±5%) | |
| Current | <100Ma | |
| Interface | USB | |
| Indication light | 1 DUAL LED,1 BUZ | |
| Working temperature | -10 ~ +70 degree | |
| Storage temperature | -20 ~ +80 degree | |
| Max. humidity | Relative humidity 0 ~ 95% | |
| Size | 75 x 21 x 7mm | |
| Operation system | WindowsMacintoshLinuxAndroid | |
How to USE ?
1. Connect the RFID USB Pen Reader to the computer USB port.
2. The reader will ‘drip’ sound and flash about that power successfully, and then half a second after the ‘drip’ sound and flash about that device selftest successfully, without Install any drivers, windows will automatically recognize it.
3. Open one EXCEL or WORD ,the card number would be input by itself .Connect USB pen reader to OTG cable , OTG cable to smartphone , open any file can type letters, the card number would be input by itself.
Physical Details
Tunnel size: 500(W) x 300(H) mm.
Product dimensions: 2170mm(L)x720mm(W)x1193mm(H).
Wooden Package dimensions: 1750mm(L)x850mm(W)x1400mm(H).
Shipping weight: Net weight: 280kg. Gross weight: 310 kg.
Working temperature: (-20)℃~(+60)℃/Humidity 5% to 95%, non-condensing.
Storage temperature: (-30)℃~(+70)℃/Humidity 5% to 95%, non-condensing.
Power supply: 110~240VAC (-10%~ +20%),50/60±3Hz.
Power consumption: < 0.5 kw/h.
Certificates: Meets electrical safety and compatibility requirements for CE(EMC Directive~2014/30/EU and LVD Directive~2014/35/EU),ROHS (Directive~2011/65/EU).
X-RAY Generator
X-ray tube head: Self-contained
Tube voltage rating: 80 kV(default), can be tailor-made based on requirement. Tube current: 0.2~0.6 mA.
Cooling/working period: 100% with sealed oil bath cooling.
Beam direction: Diagonal from bottom (60°beam divergence)
X-ray leakage dose: Less than 0.35 μGy / h (5cm distance from any position of the machine) .
Single scanning x-ray leakage dose: Less than 1 μGy / h.
High X-ray leakage protection: Two levels lead curtains to reduce the leakage, and protect operators.
Inspection Performance
Steel penetration: 10~15 mm typical.
Conveyor speed: 0.22m/s
Conveyor height: 740mm(including the support tray )
Wire Resolution: 38 AWG wire,40 AWG(0.0787 mm) typical
Space Resolution: Horizontal Φ 1.0mm; vertical Φ 1.0 mm
Noise: <55dB
Max. Load Weight: 150 kg (331 lbs.)
Film Safety: Guaranteed for high-speed film up to ISO 1600 (33 DIN).
Detectors
The array detector: L-type photo-diode single/dual energy detector.
Video
19 inch color LCD monitor, pixel 1280 x 1024 video card.
Image Performance System
Auto Soft operating system: Win 7 English version.
Standard Functions: High & Low penetration/Super penetration/Organic & in-organic image/local & edge enhancement/zoom in & zoom out/Image resolution/Image storage/Image management/Black & white image/Gray image/Belt forward & reversal/Marks. Time & date/Power on indicator/Self diagnostic function/System log/Baggage counts/TIP function/User management.
Image storage: 100,000 images can be stored and process continuously.
Pull back/forward: 30 images to process.
32x smart zoom: Adjustable zoom preview window.
Other Functions
Alarm function: Liquid and high density substances will give audio & indicator alarm with a red frame.
Networking function: Can be connected to a dedicated virtual LAN configured tested by the assigned communications subcontractor.
Images output: Images can be put out with USB interfaces.
Options
BI-direction(two-direction) scanning.
Customized roller stand.
Customized software language(Basic is English).
]]>
